Description
| Series | 18 |
| Operating principle | Reflection principle |
| Application | Detection of highly transparent bottles Detection of highly transparent films and glass panes |
| Special version | Autocollimation Warning output |
| Operating range | 0 … 2.4 m |
| Operating range limit | 0 … 3 m |
| Light source | LED, Red |
| Protective circuit | Polarity reversal protection Short circuit protected |
| Supply voltage UB | 26.5 … 31.6 V |
| Open-circuit current | 0 … 35 mA |
| Switching frequency | 500 Hz |
| Response time | 1 ms |
| Type | AS-Interface IO |
| Type of connection | Connector |
| Thread size | M12 |
| Material | Stainless steel |
| No. of pins | 4 -pin |
| Dimension (W x H x L) | 15 mm x 50 mm x 33 mm |
| Housing material | Metal |
| Metal housing | Zinc |
| Lens cover material | Glass |
| Net weight | 75 g |
| Type of fastening | Mounting thread Through-hole mounting |
| Operational controls | Multiturn potentiometer |
| Ambient temperature, operation | -25 … 55 °C |
| Degree of protection | IP 67 IP 69K |
| Protection class | III |
| Certifications | c UL US |
| Standards applied | IEC 60947-5-2 |
